Introducing the Mitutoyo Quick Image

with Metlogix M3 Software

Discover the ultimate in simple, non-contact measurement precision with the Mitutoyo Quick Image vision system with Metlogix M3

This integration seamlessly combines ease of use with cutting-edge technology to make the Quick Image even more powerful with an intuitive, icon-driven interface and robust tolerancing and programming options.

Easy to use

missing images big blocks plus discover our studies.png

The Mitutoyo Quick Image vision system features a straightforward, intuitive user interface that simplifies complex measurement tasks. Thanks to the new Metlogix M3 software, the Quick Image touchscreen interface with gesture controls makes navigation effortless, allowing users to quickly access functions and settings. The system’s image stitching capabilities measure parts larger than the field of view, and its icon-driven design ensures that even users with minimal training can operate the system effectively.

Specifications

	Manual QI-A1010D	Manual QI-A2010D	Manual QI-A2017D	Manual QI-A3017D	Manual QI-A4020D	Motorized QI-C2010D	Motorized QI-C2017D	Motorized QI-C3017
Measuring range (X x Y)	3.94″ x 3.94″ 100×100mm	7.87″ x 3.94″ 200×100mm	7.87″ x 6.69″ 200×170mm	11.8″ x 6.69″ 300×170mm	15.7″ x 7.87″ 400×200mm	7.87″ x 3.94″ 200×100mm	7.87″ x 6.69″ 200×170mm	11.8″ x 6.69″ 300×170mm
Maximum stage loading*	Approx. 22 lbs.(10kg)	Approx. 22 lbs.(10kg)	Approx. 44 lbs.(20kg)	Approx. 44 lbs.(20kg)	Approx. 33 lbs.(15kg)	Approx. 22 lbs.(10kg)	Approx. 44 lbs.(20kg)	Approx. 44 lbs.(20kg)
Main unit mass	Approx. 143 lbs. 65kg	Approx. 152 lbs. 69kg	Approx. 330 lbs. 150kg	Approx. 348 lbs. 158kg	Approx. 361 lbs. 164kg	Approx. 158 lbs. 72kg	Approx. 337 lbs. 153kg	Approx. 354 lbs. Approx. 161kg

M3 Integration

Metlogix M3 is an intuitive and thoughtful icon-driven user interface with a flexible probe library and powerful tolerancing and programming making it ideal for video measurement solutions. The M3 software enhances the versatility of the Mitutoyo Quick Image by offering a range of advanced features that further expands the Quick Image’s already extensive and versatile capabilities. The software’s ability to handle gesture controls on the touchscreen further streamlines operations, making the Quick Image system adaptable to a wide array of industrial measurement needs.

Powerful Combination of Precision, Versatility & Ease of Use

The new Mitutoyo Quick Image system with M3 software is a smart investment, offering a perfect blend of innovative technology and ease of use, making it ideal for highly accurate and efficient non-contact measurements. The system enhances efficiency by streamlining measurement processes with its intuitive interface and gesture controls, significantly reducing setup and measuring times, boosting productivity and efficiency without sacrificing precision. The M3 software’s advanced features make it easy to handle even the most complex tasks with minimal effort.

Benefits of the Mitutoyo QI with M3 Software

Image stitching capabilities up to 400mm for easier, more efficient image measurements

Large 22mm depth of field greatly reduces human focusing and measurement errors

Part recognition automatically loads and runs the correct part program

Ultra-long 90mm working distance ensures safe focusing without worrying about collisions

A simple, intuitive interface on the M3 touchscreen that supports gesture controls

DXF Overlays and Profiling allow GO/NO-GO overlays and deviation whisker charts

Optional Thread module that automatically measures threads

Pattern-based playback and alignment allow parts to be placed anywhere on the stage without fixturing

Advanced video and optical edge detection, even on large and stepped workpieces

Powerful tolerancing and programming ideal for video measurements
