Quick Vision Active

Precision You Can Count On

Compact, high-quality optics, robust edge-detection, traceable.

Meet the QV Active Series

The QV-Active series is a versatile vision measuring machine designed for both non-contact and tactile measurements. Its compact footprint and advanced optics make it ideal for quality control in various industries, ensuring accurate results with minimal operator intervention.

Want more information?

Upgrade Productivity and Measurement Confidence in 3 Ways

Precision

Achieve high accuracy with advanced optics and a robust edge-detection system.

Flexibility

Wide application spectrum for both non-contact and tactile applications.

User-Friendly

Operators can quickly learn to use the system, reducing training time significantly.

Key Features and Benefits

High-Speed Precision

Faster cycles with real CMM accuracy for production environments.

Up to 40% faster measuring cycles compared to traditional methods.

Traceable Metrology

Ensures reliable and traceable measurement results.

QV-Active achieves an accuracy of approximately 3 microns across all three axes.

User-Friendly Software

Operators are up to speed in 1–2 days with intuitive workflows.

The system features a high-resolution colour camera and an 8-position zoom optical system.

Hybrid System

Combines tactile and optical measurement capabilities.

Operators can be trained to use the system within 1-2 days due to its user-friendly interface.

Compact Design

Fits seamlessly into existing production environments.

The QVPAK software suite has over 30 years of proven experience in vision measurement.

TWO MODELS

EACH A BUNDLED FORCE BOTH: FITTING TO YOUR NEEDS. AND YOUR BUDGET.

For a limited time each model bundle comes as an fully integrated PRECISION KIT Solution. Consisting of extras, all-ready included as:

HYBRID TACTILE AND OPTICAL SYSTEM WITH 1.5 X LENS
POWERFUL QVPAK SOFTWARE
CALIBRATION CHART WITH HOLDER

QV ACTIVE 202

SMALL FOOTPRINT.
BIG IMPACT.

250 x 200 x 150mm

PRECISION BUNDLE QV 202

from 29.999,- €*

QV ACTIVE 404

WIDE RANGE.
HIGH FLEXIBILITY.

400 x 400 x 200mm

PRECISION BUNDLE QV 404

from 41.500,- €*

Our Z-objective lenses are at the top range of what you can get in the industry. Unique and unmatched in price/performance ratio. They deliver highest accuracy in 3 Zoom Ranges and even 3 axis and dimensions, each.

The Precision Bundle includes the standard 1.5x Lens. Two optional lenses are available at a special price for a limited time. Giving you the precision you need, at all scales, fit for every measuring challenge.

3x3 - Everything at once:

WIDE, MID, CLOSE.

AND X, Y, Z.

Unmatched lenses that provide unmatched in-depth accuracy.

SPECIAL OFFER - What's included in the bundle?

✓ Calibration chart with holder.

✓ Powerful QVPAK software.

✓ Hybrid tactile and optical system with 1.5x lens.

✓ Calibration chart with holder.

49.000 €

The full automation-ready CMM bundle

Special Offer from: 49.000 €

WANT TO FIND OUT HOW MULTI-SENSORS BOOST FLEXIBILITY AND EXPAND THE CAPABILITIES OF STANDARD VISION SYSTEMS?

Find out in our latest whitepaper!

DOWNLOAD WHITEPAPER

What Our Customers Say

"We have been working with Mitutoyo for many years and have always encountered great professionalism in service, as well as products of great quality and reliability.

The automotive world, of which DELLORTO is a part, has very demanding measurement requirements: with the support of Mitutoyo, we are able to guarantee the satisfaction of our customers."

Roberto Rota
Quality & Environment Manager | DELLORTO

Get the Offer and Full Details

Fill out the form to request informations, connect with a sales expert or sign up to our newsletter!

Personal Information

Salutation

First name*

Last name*

E-mail*

Company*

Postcode*

City*

Street*

Country*

Phone

Subject

How can we help?*

Which Product you are interested in?*

Comments*

More information

Please keep me up-to-date about products, promotions and events on a regular basis

What industry are you in?*

How did you get to know us?*

I accept the General Terms and Conditions of Use for Internet Sites and Their Contents of Mitutoyo Europe GmbH

* mandatory

FAQ

What are the environmental conditions for operating the QV-Active?

A QV-Active can operate in a clean production environment or a separate measurement/inspection room.

Does the QV-Active need compressed air for operating?

No, the QV-Active is equipped with mechanical high rigid and precise linear bearings.

What is the maximum weight of the workpiece which can be put on the glass stage?

The maximum stage load is 10 kg for QV-Active 202 and 20 kg for QV-Active 404.

What is the footprint of the QV-Active?

The machine footprint excluding a computer desk is 570 x 767 mm for QV-Active 202 and 776 x 1303 mm for QV-Active 404.

Does the QV-Active have a machine stand as standard delivery or is this optional?

For both QV-Active 202 and 404, the machine stand is standard accessory.

Can the QV-Active be connected and communicate with external systems like robots for automatic loading and unloading?

Yes, for QV-Active a special I/O communication software is available (option).
